Mixing Bowl Tipper - Multi Bowl

# Part Number:
600/HT300-1035
  • Lifts mixing bowls via twin hydraulic rams.
  • The unit tips its contents safely and efficiently onto acceptance conveyors, tables or into smaller receiving bins or buggies.
  • Bespoke carriage design to allow multiple bowl types to be handled on a single machine
  • The unit suits most applications and can be mobile or static.
  • Supplied with side guarding as standard.
  • Maximum tipping height up to 1350mm.
MORE Mixing Bowl Tipper - Multi Bowl FEATURES


Enquire For Price

  • Lifts mixing bowls via twin hydraulic rams.
  • The unit tips its contents safely and efficiently onto acceptance conveyors, tables or into smaller receiving bins or buggies.
  • The unit suits most applications and can be mobile or static.
  • Supplied with side guarding as standard.
  • Tipping angle range: 125° max from lowered position - 35° from horizontal position
  • Maximum tipping height up to 1350mm.
  • Material: 304 stainless steel
  • Capacity: To suit application or container
  • Finish: Bead Blast
  • Electrical Requirements: 400 volt 3 phase neutral and earth
  • Control voltage: 24 volts
  • Safe working load: 600-1500kg
  • Protection: IP65
  • Features:
    Hold to run
    Tested to 1½ times SWL
    Electro-Hydraulically Powered
  • Options:
    Electronically interlocked gates
    Static or mobile
