Mixing Eurobin Tumbler - Door Open

Mixing Eurobin Tumbler

Clean Line High Capacity Eurobin Tumbler

Clean Line High Capacity Eurobin Tumbler

High Capacity Eurobin Tumbler

High capacity Eurobin tumbler is designed to offer high quality, consistent and safe mixing of food and nutraceutical ingredients using a unique bi-directional mixing method. Suitable for use with both 200L and 300L Eurobins.

  • Perfect solution for mixing, marinating, infusing and coating products
  • The flexibility to mix products using both DIN9797 200 litre and 300 litre Eurobins
  • Reduces product wastage, no mixing arms or paddles
  • Bi-directional mixing method ensures no dead spots resulting in a homogenous mix
  • Programmable HMI multi recipe system with create, save and recall functions to ensure consistent results
  • Pre-set clean and seal change modes for quick product changeovers
  • Vacuum assist is optional, this allows the air to be removed from within the Eurobin and machine mixing hood prior to tumbling. This offers a significant reduction in marinating time and improving overall final product results making it a perfect solution for marinating, infusing and coating products
  • Safe maintenance and wash down programs
  • Fully guarded and incorporating an interlocked gate for complete safety


Looking for more Eurobin handling equipment?
View the full range of Eurobin equipment here.




Starting at £0.00

SKU CODE: 600/TT2
Grouped product items
Product Name Qty
High Capacity Eurobin Tumbler - With Vaccum Assist
600/TT2_Vac
£0.00
High Capacity Eurobin Tumbler - Without Vaccum Assist
600/TT_NoVac
£0.00

Documents

Downloads for High Capacity Eurobin Tumbler

The SYSPAL range of Eurobin Tumblers are specifically designed to offer high quality, consistent and safe mixing of food ingredients. Industry standard DIN9797 Eurobins mix product without the use of rotating blades or paddles. This unique method of mixing prevents “dead-spots” that often occur as a result of Z-blade or paddle mixing. Delicate products are mixed effectively with significant reduction in damage, resulting in the highest levels of mix consistency and final product presentation. The combination of SYSPAL’s Eurobin Tumbler and Single Bin Solution range enables weighing, mixing, tipping, storage and washing to be carried out using a single Eurobin.

Key product features include:

  • Significantly reduces product damage due to the non-use of rotating Z-blades or paddles
  • Increased production efficiency by reducing product transfer and handling when integrated into the SYSPAL Single Bin Solution process
  • Large capacity hood and user speed control ensures free-movement of product while tumbling, ensuring the best quality mix in the shortest period of time
  • User friendly operator controls via panel mounted HMI display
  • Reduces injury risks associated with manual handling


 Processes:

  • Mixing
  • Blending
  • Coating
  • Massaging
  • Tumbling
  • Marinating
  • Infusing


 Small sample of products ideally suited to this application:

  • Chicken wings, drumstick and thighs for marinating
  • Ribs and coated meats with dry rubs
  • Potato wedges with seasoning
  • Prepared root vegetables with herbs
  • Nutraceutical products

  • Material: 304 Stainless Steel
  • Finish: Bead blast
  • Electrical Requirements: 400V 3 Phase 50-60hz
  • Pneumatic Requirements: 6 bar air supply
  • Motor Size: 3 kW
  • Protection: IP65 rated electrical enclosure
  • S.W.L: 350kg
