Mixing Eurobin Tumbler

    The Eurobin tumbler uses a unique angular bin rotation that 'folds' the ingredients, producing a high quality homogeneous mix. Ideal for handling difficult recipes with delicate ingredients that require minimal mixing.

    • Perfect solution to blend and mix products inside DIN 9797 industry standard 200 litre Eurobins
    • Designed to save on labour and increase production efficiency
    • Reduces product wastage
    • Bi-directional mixing method
    • HMI multi programmable recipe system
    • Safe maintenance and wash down programs
    • Unique cross corner rotation
    • Fully guarded and incorporating an interlocked gate for complete safety
    Dimensions: (Length x Width x Height unless stated)
    • L2470 (open) x W1751 x H1776


    Looking for more Eurobin handling equipment?
    View the full range of Eurobin equipment here.




£0.00
SKU CODE: 600/TT100

Documents

Downloads for Mixing Eurobin Tumbler

The SYSPAL range of Eurobin tumblers are specifically designed to offer high quality, consistent and safe mixing of food ingredients whilst minimising product wastage. Industry standard DIN9797 Eurobins mix product without the use of rotating blades or paddles. This unique method of mixing prevents “dead-spots” that often occur as a result of Z-blade or paddle mixing. Delicate products are mixed effectively with significant reduction in damage, resulting in the highest levels of mix consistency and final product presentation. The combination of SYSPAL’s Eurobin tumbler and Single Bin Solution range enables weighing, mixing, tipping, storage and washing to be carried out using a single Eurobin.

Key product features include:

  • Significantly reduces product damage due to the non-use of rotating Z-blades or paddles
  • Increased production efficiency by reducing product transfer and handling when integrated into the SYSPAL Single Bin Solution process
  • Large capacity hood and user speed control ensures free-movement of product while tumbling, ensuring the best quality mix in the shortest period of time
  • User friendly operator controls via panel mounted HMI display
  • Consistent results achieved via programmable recipe create, save and recall function
  • Bi-directional rotation of the Eurobin, vastly improves product mix quality
  • Quick product change over utilising pre-set clean and seal change modes
  • Reduces injury risks associated with manual handling


 Processes:

  • Mixing
  • Blending
  • Coating
  • Massaging
  • Tumbling
  • Marinating
  • Infusing


 Small sample of ingredients ideally suited to this application:

  • Rice products
  • Pasta products
  • Ready meals
  • Drinks powders
  • Herbs, spices and seasonings
  • Prepared vegetables and salads

  • Material: 304 Stainless Steel
  • Finish: Bead blast
  • Electrical Requirements: 240V
  • Pneumatic Requirements: 6 bar air supply
  • Motor Size: 3 kW
  • Protection: IP65 rated electrical enclosure
  • S.W.L: 250kg
