Dolav Tipper 1500

# Part Number:
600/HT4
  • 1500kg Capacity
  • 304 Grade Stainless Steel
  • Tipping Height: Up to 1350mm
  • Tipping Angle up to 125 degrees
  • Bespoke carriage design to accommodate: Dolav, Containers, Bowls, Tanks
  • Mobile or Bolt Down Base
  • Battery or 3 Phase Mains Power


MORE Dolav Tipper 1500 FEATURES


Dolav Tipper 1500 Download Specification TECHNICAL SPECIFICATION
Options Available

* Required Fields

£0.00

Documents

Downloads for Dolav Tipper 1500

Dolav Tipper 1500 Download Specification TECHNICAL SPECIFICATION

  • Designed for lifting Dolav containers, plastic pallet boxes, CHEP or industrial containers to a safe height for manual unloading by hand.
  • Reduces operator bending fatigue by providing a constant access height.
  • Fully mobile.
  • Battery operation allows the unit to be used anywhere required within the working environment.
  • Hydraulic tippers can also be designed to lift a range of tanks or containers on request.
  • Material: 304 Stainless Steel
  • Capacity: Dolav Container
  • Maximum Tipping angle:  up to 125° from lowered position - 35° from horizontal
  • Tipping height: up to 1350mm
  • Finish: Bead Blast
  • Electrical Requirements: 12 volt battery or mains powered 3 phase 240v
  • Features:
    Electro-Hydraulically Powered
    1500kg S.W.L.
    2 fixed wheels, 2 swivel braked castors with nylon wheels.
